Technical Specifications |
|
|
Main Purpose: |
By low-temperature grinding of biological samples, nucleic acid degradation can be effectively inhibited, protein activity can be preserved, and samples can be processed in large quantities. It has the functions of tissue homogenization, grinding, cell disruption, homogenization, material dispersion, preparation, and vibration. |
|
Related Core Technologies: |
Adopting the "multi-substance grinding and extraction" and "rapid grinding function of cell crushing device" technologies, it can grind and crush any source of samples (including soil, plant and animal tissues/organs, bacteria, yeast, fungi, spores, fossils, etc.). Raw DNA, RNA, and proteins can be extracted and purified, and it can process 24*2ML/12*5ML. It can process 24 samples at the maximum processing capacity within 15 seconds. |
|
Display Method: |
Touch screen display, user-friendly interactive design, convenient operation, can be operated conveniently and intuitively, with electromagnetic lock function, automatic opening and closing function on the screen, reducing manual operation. |
|
Data Storage: |
It can store ten sets of experimental data, and according to different experimental samples, it is set with animal heart, spleen, lung, kidney, bone, skin, hair modes. According to the set experimental parameters, it can continuously cycle among several set parameters, further reducing human interference factors. |
|
Simplified Test Tube Compression Technology: |
For the fixed part of the grinding tube, the "simplified test tube compression" technology is adopted to reduce the risk of tube breakage. Together with reliable compression technology, it can ensure the integrity of the grinding tube for high-intensity grinding work. |
|
Homogeneous speed: |
1-21M/S, working time: 1-9999S, user can set it by themselves. |
|
Safety: |
The instrument adopts a double-layer shock absorption structure to ensure that the instrument remains stable during high-speed grinding work, does not interfere with external instruments, and ensures the safety of the overall environment. |
|
Grinding ball material: |
Alloy steel, chrome steel, zirconia, tungsten carbide, and quartz sand. |
|
Noise level: |
<54db. |
|
Cooling function: |
Adopting the "grinding device with freezing function" technology, it can be adjusted from -50℃ to room temperature. Temperature control accuracy: ±0.5℃. Effectively solve the problem of sample denaturation and agglomeration caused by rapid heating during the grinding process, and improve the success rate. |
|
Automatic centrifugation function: |
Using the "dual-motor rotating centrifugation" technology, with centrifugation function, the highest grinding speed can be set to 6000 revolutions, realizing the integration of grinding and centrifugation. |
|
Grinding method: |
Wet grinding, dry grinding, and low-temperature grinding are all available. |
|
External dimensions: |
70*41.5*51cm |
|
Weight: |
82 kg |
